PHILIPS 830A
- Manufacturer/Brand: Philips - Schweiz
- Year: 1931–1933
- Principle: TRF without reaction (non reg.dir.receiver)
- Tuned circuits: 2 AM circuit(s)
- Wave bands: Broadcast (MW) and Long Wave.
- Power type and voltage: Alternating Current supply (AC) / 110-240 Volt
- Loudspeaker/pwr.out: Magnetic loudspeaker (reed) of high quality (4 magnet poles). / Ø 28 inch = 71.1 cm
- Material: Bakelite case
- Shape: Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
- Dimensions (WHD): 410 x 490 x 220 mm / 16.1 x 19.3 x 8.7 inch
- Valves / Tubes: 5: E452T, E452T, E424N, C443, 506
- Net weight (2.2 lb = 1 kg): 11.5 kg / 25 lb 5.3 oz (25.33 lb)
- Price in first year of sale: 365.00 SFr.
